4-8 meters street light pole with Customizable Length and Shape for Different Applications

1 40HQ
MOQ
협상 가능
가격
4-8 meters street light pole with Customizable Length and Shape for Different Applications
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
치수 공차: +- 2%
바람 저항: 3-500km/h
재료: GR50 GR65 S500 S355
키: 4-8 미터 길이의 빛 기둥
용접: 용접은 CWB의 국제 용접 표준으로 확인합니다
분말 코팅: 순수한 폴리 에스테르 파우더 페인팅, 색상은 선택 사항입니다
설계: 지진 중 8 학년에 반대하여
제품 이름: 4-8 미터 다른 응용 분야의 맞춤형 길이 및 모양을 가진 거리 조명 기둥
기본 정보
원래 장소: 중국
브랜드 이름: Milky Way
인증: ISO//BV
모델 번호: 4-8 미터 다른 응용 분야의 맞춤형 길이 및 모양을 가진 거리 조명 기둥
결제 및 배송 조건
포장 세부 사항: 고객 요청에 따라
배달 시간: 보통 확인하는 것 2 주 뒤에
지불 조건: t/t
공급 능력: 300개 부분은 하루에 막대기를 씁니다
제품 설명





Specification:



Specification: 4-8 meters street light pole
Type street light pole
Shape conical, hexagonal and octagonal
Material Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
Torlance of dimenstion -0.02
Design Load in Kg 300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Standard Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123
Length of per section Within 14m once forming without slip joint.
high mast pole suit for city square,wharf,stadium
Option of high mast pole Height from 20m to 35m
Flange mounted or planted type
Production Process of high mast pole Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration→Thread →Packages



4-8 meters street light pole with Customizable Length and Shape for Different Applications 0





·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,







4-8 meters street light pole with Customizable Length and Shape for Different Applications 1
