Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

1 개 PC
MOQ
협상 가능
가격
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
제품 이름: 직류 전기로 자극된 파워 폴대
모양: 8각형이거나 라운드
전력 용량: 10kV 내지 220kV
막대기의 조인트: 활동 이음쇠
보증 시간: 15 년
두께: 1 밀리미터 내지 36 밀리미터
강조하다:

galvanized steel power transmission poles

,

25ft-40ft power transmission poles

,

10kV-220kV power transmission poles

기본 정보
원래 장소: 중국
브랜드 이름: MilkyWay
인증: ISO9001/BV/
모델 번호: 전송 강철 파워 폴대
결제 및 배송 조건
포장 세부 사항: 고객 요청으로
배달 시간: 20 당신의 대금을 받은 후 일로 일합니다
지불 조건: 시야에 t/t, l/c
공급 능력: 일 당 300 PC
제품 설명
Galvanized Steel Power Transmission Poles for Utility Lines
Available in 25ft, 30ft, 35ft, and 40ft lengths with competitive pricing
Product Specifications
Product Name Galvanized Power Pole
Shape Octagonal Or Round
Power Capacity 10kV to 220kV
Joint of Poles Slip joint
Warranty time 15 years
Thickness 1 mm to 36mm
Steel Material Quality
All materials are sourced from reputable mills to ensure quality. Each shipment includes a mill certificate with stamp and signature for verification before unloading.
Before production, all materials undergo rigorous chemical and physical analysis to confirm they meet required strength and composition standards.
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 0
Detailed Specifications
Types Length 45ft 50ft 55ft 60ft 65ft 70ft
13.75m 15.25m 16.80m 18.30m 19.85m 21.35m
B (0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
Manufacturing Tolerances
  • Component Length: -25mm to 75mm
  • Straightness: 2mm/m
  • Twisting degree: 1° per 3 meters length
  • Ovalisation: Maximum is 3%
  • The average diameter: +/-0.5%
  • Slip length: +/-150mm
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 1
Welding Standards
Our welding processes have passed flaw testing. We use internal and external double welding for both strength and aesthetic quality.
Welding Standard: AWS (American Welding Society) D 1.1
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 2
Surface Treatment
Hot dip galvanized following ASTM A 123 standards. Custom color polyester powder or other client-required finishes available.
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, has over 24 years of experience manufacturing steel poles including transmission power poles, street light poles, and high mast poles.
Since 1991, we've exported to over 70 countries worldwide including the USA, Australia, Russia, Germany, Spain, Philippines, Malaysia, and throughout Africa.
We've supplied major projects globally, including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 3
