12m 1200 Dan Hot Dip Galvanized Utility Power Poles

1 PC
MOQ
협상 가능
가격
12m 1200 Dan Hot Dip Galvanized Utility Power Poles
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
타입: 11.88m-1200dan 설계하중 철골 전신주 전기 장비 전주판
형태: 원추형인 라운드
지불 조건: T/T, L/C
두께: 2.5mm-16mm
지상 완성되는: 직류 전기를 통하는 뜨거운 복각
표준: /BV/ISO9001
강조하다:

12m utility power poles

,

1200 Dan utility power poles

,

HDG utility power poles

기본 정보
원래 장소: 장쑤 성, 중국
브랜드 이름: Milky Way
인증: /BV/ISO9001
모델 번호: 강철 전화선용 전주
결제 및 배송 조건
포장 세부 사항: 고객의 요구
배달 시간: 10-30 작업 일은 후에 당신의 지불금을 받았습니다
지불 조건: T/T, 보자마자 L/C
공급 능력: 달 당 30,000 톤
제품 설명

12m 1200 Dan Load Electric Steel Utility Power Poles Hot Dip Galvanized





Features:



 Pole’s height

All available

Type

Straight Pole ,Tensile Pole ,Turn Pole,etc

Shape of pole

Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, etc

Crossarm

 Single or double crossarm, dimension as per customers’ requirement

Material

Steel materials conform to ASTM A36,

Q235 equivalent to SS400, S235JO. Q345 equivalent to S355JR,Grade 50

Q460 equivalent to S460, Grade 65

 Wall thickness

≥2.5mm

Once forming

13m without joint



Welding

Welding complies with CSA and AWS, AWS D1.1 standard.

The welders have got corresponding certificate after testing and inspection.

 Joint

 Joint with insert mode, flange mode.

Base plate mounted

Base plate is square or round with slotted holes for anchor bolt and dimension as per client’s requirement.

 Galvanizing

Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 orAmerican standard ASTM A123.

Voltage

 10KV~550KV

Certificates

 ISO9001-2008 , AAA credit rating, etc

Protection

Anti-corrosion and rust free – suitable for coastal area, desert, oil field and industrial area



12m 1200 Dan Hot Dip Galvanized Utility Power Poles 0

Packing & shipping





We use sack package the poles or straw at the pole top and bottom which is our normal package. We also use wood between the poles but cost just little higher than normal package. We normally use 40HQ container and our Port limit weight for 40HQ is 26Ton.











Our Servises:





1.Reply your inquiry in 24 working hours.



2. Experienced staffs answer all your questions in fluent English.



3. Customized design is available. UEM&UBM are welcomed.



4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.



5. Special discount and protection of sales are provided to our distributor.



6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.



 7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.



8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
